Linking Conveyor

  • Technical Details

Features

1 Designed for SMT production line, provide the connection between the whole line, to increase the special process positions
2 Sturdy aluminum profile structure design
3 Smooth and parallel width adjustment
4 Belt or chain drive optional (Price different)
5 Adjustable transfering speed
6 Optional lighting
7 Optional inspection station
8 Multi stages optional
9 Single or Dual Lane Available
10 Anti-static design, ESD cover optional
11 Telescopic function available for special needs
12 Lifting functions for special needs are available
13 Support Multiple PCB size
14 Different lengths can be customized according to customer demands


Linking Conveyor
